Lapp ÖLFLEX® H07Z-K 90° Series Blue 1.5 mm² Hook Up Wire, 15 AWG, 100m, 4726021

Low Smoke Halogen Free Single Core Cable - H07Z-K From Lapp, this low smoke zero halogen cable is designed for use in internal wiring. The single core harmonized cable can be used to wire appliances and fittings, and is also ideal for installation in conduits and sealed trunking. As it is low smoke zero halogen (LSZH) it is suitable for environments where the protection of people and equipment is paramount. In the event of a fire, this wire will release far less smoke and no harmful halogens when burning compared to non-LSZH wiring. With a fine copper wire construction, the wire also features a halogen free core. The cable is also certified, meaning it is suitable for use in most European machinery. Features and Benefits • LSZH • H07Z-K 90°C • Harmonized (HAR) • Flame retardant in accordance to IEC 60332-2-2 • Smoke density in accordance to IEC 61034 • Halogen free in accordance to IEC 60754-1 • Operating Temperature of Temperature range -15°C → +90°C Cross Sectional Area 1.5 mm² Sheath Colour Blue American Wire Gauge 15 AWG Cable Shape Single Core Length 100m Voltage Rating 750 V Outer Diameter 3.5mm Minimum Operating Temperature -15°C CPR Certification Eca Maximum Operating Temperature +90°C Conductor Material Copper Wire Style 2491B Series ÖLFLEX® H07Z-K 90°
