DC Relay with Base 24V 14Pin

Product Specification: DC Relay with Base 24V 14Pin Overview: This product is a robust and reliable DC relay designed for switching electrical circuits in various industrial and commercial applications. It features a 24V DC coil voltage and a 14-pin base for easy integration and connection. The relay is supplied with a corresponding socket base, simplifying installation and maintenance. Typical Specifications: Coil Voltage: 24V DC Number of Pins: 14 Contact Configuration: Typically multiple poles (e.g., DPDT, 3PDT, 4PDT) Contact Rating: Varies by specific model, commonly 5A, 10A, or higher at 250V AC / 30V DC Insulation Resistance: Typically > 100 MΩ at 500V DC Dielectric Strength: Varies by specific model, commonly 1000V AC for 1 minute between contacts and coil, and between open contacts. Operating Temperature: -40°C to +70°C (typical range) Storage Temperature: -40°C to +85°C (typical range) Vibration Resistance: 10-55Hz, 1.5mm double amplitude (typical) Shock Resistance: 10g, 11ms (typical) Lifespan (Electrical): Typically 100,000 operations at rated load Lifespan (Mechanical): Typically 1,000,000 operations (typical) Common Features: High Reliability: Engineered for consistent and dependable operation. Compact Design: Space-saving footprint for efficient panel mounting. Durable Construction: Built with high-quality materials for longevity. Easy Installation: Supplied with a pre-wired or screw-terminal socket base for quick setup. Indicator Options: May include an LED indicator for coil energization status. Protection Options: Some models may offer surge suppression or protection diodes. Clear Pin Identification: Marked pins on the relay and base for straightforward wiring. Standard Technical Details: Coil Power Consumption: Typically 0.5W to 1.5W (varies by model) Operating Time: Typically < 15ms Release Time: Typically < 10ms Contact Material: Typically silver alloy (e.g., AgNi, AgCdO) for good conductivity and arc resistance. Mounting Type: Socket mount via the included base. Enclosure Type: Typically dust-proof or sealed for protection against environmental factors. Compliance: May comply with relevant standards such as UL, CE, RoHS.
